Outdoor Lighting / Urban LightingVektor
BACK
| Housing | Corrosion Resistant Aluminum Injection Body |
| Pole | Corrosion Resistant Galvanized Steel Body |
| Optics | PMMA Lens + Glass |
| Paint | Electrostatic Powder Paint |
| Optics | Symmetrical 60° / Asymmetrical 150° |
| Light Output Angle | Symmetrical 60° / Asymmetrical 150° |
| UGR Value | UGR ≤ 25 |
| CRI | CRI ≥ 80 |
| Color Bin Value | Mc Adams ≤ 3 |
| Colour Options |
 |
| Order Code | W | Lm | CCT | WxH (mm) | Productivity | Technical Page | Photometric File |
|---|---|---|---|---|---|---|---|
| 09594.63.30.058 | 3x15 | 5600 | 3000 | 600x3000 | 130 Lm/W | Technical Page | |
| 09594.63.40.058 | 3x15 | 5850 | 4000 | 600x3000 | 130 Lm/W | Technical Page | |
| 09594.63.30.117 | 3x30 | 11200 | 3000 | 600x4000 | 130 Lm/W | Technical Page | |
| 09594.63.40.117 | 3x30 | 11700 | 4000 | 600x4000 | 130 Lm/W | Technical Page |
| IP Rating | IP65 |
| IK Rating | IK08 |
Shopping Mall
Air Field
Parking lot
