Indoor Lighting / Recessed LightingPera
BACK
| Housing | Metal Sheet |
| Diffuser | High Transmittance Opal Diffuser |
| Paint | Electrostatic Powder Paint |
| Optics | Symmetrical |
| Light Output Angle | 120° |
| UGR Value | UGR ≤ 19 |
| CRI | CRI ≥ 80 |
| Color Bin Value | Mc Adams ≤ 3 |
| Colour Options |
   |
| Order Code | W | Lm | CCT | CRI | L (mm) | Cut-out dimensions (mm) | Technical Page | Photometric File |
|---|---|---|---|---|---|---|---|---|
| 02182.36.30.021 | 21 | 2200 | 3000 | Ra>80 | 595 | 295x585 | Technical Page | Ldt |
| 02182.36.40.022 | 21 | 2300 | 4000 | Ra>80 | 595 | 295x585 | Technical Page | Ldt |
| 02182.31.30.041 | 42 | 4400 | 3000 | Ra>80 | 1195 | 295x1185 | Technical Page | Ldt |
| 02182.31.40.043 | 42 | 4600 | 4000 | Ra>80 | 1195 | 295x1185 | Technical Page | Ldt |
| IP Rating | IP40 |
| IK Rating | IK02 |
Shopping Mall
Hospital
Air Field
Business Center
Office
