Indoor Lighting / Industrial LightingRising
BACK
| Housing | Metal Sheet |
| Diffuser | Tempered Clear Glass |
| Paint / Color | Electrostatic Powder Paint |
| Optics | Symmetrical |
| Light Output Angle | 100° |
| UGR Value | UGR ≤ 22 |
| CRI | CRI ≥ 80 |
| Color Bin Value | Mc Adams ≤ 3 |
| Colour Options |
   |
| Order Code | W | Lm | CCT | Productivity | WxHxL (mm) | Kg | Technical Page | Photometric File |
|---|---|---|---|---|---|---|---|---|
| 07301.15.40.120 | 90 | 12000 | 4000 | 135 Lm/W | 138x50x920 | 4 | Technical Page | Ldt |
| 07301.15.65.120 | 90 | 12000 | 6500 | 135 Lm/W | 138x50x920 | 4 | Technical Page | Ldt |
| 07301.15.40.160 | 120 | 16000 | 4000 | 135 Lm/W | 138x50x1200 | 5 | Technical Page | Ldt |
| 07301.15.65.160 | 120 | 16000 | 6500 | 135 Lm/W | 138x50x1200 | 5 | Technical Page | Ldt |
| IP Rating | IP65 |
| IK Rating | IK08 |
Warehouse
Factory
Air Field
Sports Hall
